B001-3 Visual Two-Electrode Battery Cell

Product overview

The B001-3 adds optical observation windows to a compression-type two-electrode battery test cell. Its sample wafers and separator are clamped between glassy carbon contacts. Specify the sample diameter and the optical access required by your measurement so the viewing arrangement, cell mounting and electrical connections can be checked together.

Specifications & ordering details

Use these parameters to define your requirement. The quotation confirms the exact supplied specification.

Material / system	PEEK body; glassy carbon contacts; optical windows
Catalog model	B001-3
Body material	PEEK
Electrode arrangement	Two electrodes
Optical access	Windows on both sides
Sample wafer sizes	10, 12 or 16 mm
Active area and flow-field design	Specify with your requirement.
Plate / current-collector materials	Specify with your requirement.
Connections and included accessories	Specify with your requirement.

Research applications

Visual battery-cell studies
In-situ observation of wafer electrodes
Two-electrode material evaluation

Before you order

Confirm sample diameter and optical clearance.
Specify electrolyte, seals and contact arrangement.
Use B001-4 when a third-electrode connection is required.

Product documents

View the source catalog for this offering. Share your grade, model and application to request the relevant specification or material documentation.

View Electrochemistry, Flow & MEA Systems — page 58 ↗Download PDF

Selection questions

What should a custom enquiry include?

For B001-3 Visual Two-Electrode Battery Cell, provide the active area, sample or electrode geometry, materials, interfaces and the operating conditions. Include drawings and identify every component in the assembly scope.

Are electrodes, membranes and accessories included?

Specify the parts required. Hardware, membranes, electrodes, gaskets, fittings and instruments should be identified separately in the quotation.
